CP900
5GHz Wireless Outdoor AP/Client
- Supports 802.11ac Wave2 technology with Qualcomm Atheros chipsets.
- Delivers up to 867Mbps wireless speeds on 5G band.
- MU-MIMO technology allows multiple devices data transfer simultaneously.
- Built-in 12dBi dual polarized antennas ensure reliable Wi-Fi connection.
- Watchdog hardware design for easy troubleshooting automatically.
- Passive PoE power supply with up to 100m power transmission.
- IP65 level dustproof and waterproof for professional structural design.
- 4KV lighting proof and 15KV ESD is resilient to all harsh environments.
- 4 intelligent LED indicators intuitively show signal strength.
- Provides AP/Client/Repeater/WISP working modes.
Spec
| Brand | TOTOLINK |
| Model | CP900 |
| Standards | IEEE 802.11ac n/a |
| Frequency Range | 5.15~5.85GHz |
| WiFi Speed | AC1200 |
| Data Rate | Up to 867Mbps |
| EIRP | < 20dBm |
| Reception Sensitivity | - TX 802.11a/n(HT20)/n(HT40) /ac(VHT80)= 24/22/22/20dBm - RX 802.11a/n(HT20)/n(HT40)/ac=-72/-68/-65/-55dBm（MP) 802.11a/n(HT20)/n(HT40)/ac=-76/-72/-69/-59dBm（ES） |
| Interface | - 1 *100BaseTX (Auto MDI/MDIX) LAN Port - 1 *GND SMA connector |
| Operation Mode | - AP Mode - Repeater Mode - Client Mode - WISP Mode |
| Network | - LAN Setup - Static DHCP Setup - WAN Setup |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
| Wireless Mode | Basic Setting, Security Setting, Advanced Setting, Multiple APs, MAC Authentication, WDS, WPS, Repeater |
| Reliability | - 6KV Lightning Protection - 15KV ESD Protection - IP65 level dustproof and waterproof |
| Circuit | Watch-dog circuit |
| Antenna | Built-in 12dBi dual polarized antennas |
| Button | 1 *RESET Button |
| Dimensions | 9.3 x 3.1 x 2.3 in. (237.5 x 79 x 58.5mm) |
| Power Supply | 24V Passive PoE |
| LEDs | 1 *Power, 1 *LAN, 4 *Signal Strength |
| Package Contents | - CP900 Wireless CPE *1 - PoE Box *1 - Power Adapter *1 - Ethernet Cable *1 - Strips *2 - Quick Installation Guide *1 |
