IC-3116W


720p Wireless H.264 Day & Night Network Camera
  • Plug-n-View for 24/7 Remote Monitoring with free EdiLife app on iPhone®, iPad® or Android®  or EdiView Finder software on computers
  • 720p HD Video Quality with high resolution and rich detail
  • Night Vision with infrared LEDs, mechanical ICR and auto light sensor
  • Motion Detection triggers snapshots or recording and sends to email and ftp
  • Wireless & Ethernet connection for flexible placement, and compatible with IEEE 802.11b/g/n products
  • Easy Setup &  WPS Support

  Get EdiLife app from:
App Store Google Play


The Edimax IC-3116W 720p wireless network camera is a versatile monitoring device ideal for monitoring your home, shop or factory during the daytime or at night. With Edimax Plug-n-View technology, no complicated setup is required and you can easily connect the camera to the cloud and monitor remotely from a smartphone, tablet or laptop. Motion-triggered snapshots and recording to email ensure that you capture every criminal event. The IC-3116W comes with a wireless interface making installation easy for any home/store/factory monitoring applications.



Plug-n-View for 24/7 Easy Remote Monitoring
Edimax Plug-n-View technology makes it easy for you to keep your yard, garage, shop, factory or other assets wherever you go. With Plug-n-View technology, you can connect your network camera to the cloud in a few simple steps and access it remotely with a smartphone, tablet, or computer no matter where you are.


IC-3116W 720p Wireless H.264 Day & Night Network Camera Plug-n-View_remote_monitoring.png











Night Vision
With a light sensor, image sensor, and IR LEDs, the IC-3116W can satisfy all security and indoor surveillance needs even in dimly lit environments. And with automatic ICR (IR Cut Filter Removal), infrared light is filtered out during the day time and allowed to pass during the night time, ensuring video color quality in comparison with other IP cameras.



IC-3116W 720p Wireless H.264 Day & Night Network Camera IC-3116W_night_vision.png











Motion-Triggered Snapshots & Recording
The powerful motion detection system built into this network camera ensures that you have evidence of a criminal event. You can pre-define an area in the monitored range for motion detection; and when motion is detected in the specified area, the network camera will produce snapshots or video footage of the event immediately.



IC-3116W 720p Wireless H.264 Day & Night Network Camera IC-3116W_motion-detection2.png











High Quality Videos
The Edimax IC-3116W is built with a wide 2.2mm lens that covers a diagonal viewing angle of 69 degrees, making it suitable for capturing video footage of a wide area with a single network camera. With a megapixel CMOS sensor, this network camera is able to capture up to 720p (1280 x 720) videos at 24 frames per second.


IC-3116W 720p Wireless H.264 Day & Night Network Camera IC-3116W_HD.png










SOFTWARE FEATURES

  • Easy remote monitoring via iPhone, iPad, Android, PC & Mac

  • High-speed  H.264 & MJPEG video compression

  • Motion detection

  • Sends motion-detected snapshots to email and FTP

  • Pre- & post-recording on motion detection

  • Viewer software to access 16 network cameras simultaneously

  • Manual/scheduled/cycle recording



IC-3116W 720p Wireless H.264 Day & Night Network Camera IC-3116W_3-steps_installation2.png

IC-3116W 720p Wireless H.264 Day & Night Network Camera Network_Camera_application2.png











APPLICATION DIAGRAM

IC-3116W 720p Wireless H.264 Day & Night Network Camera IC-3116W_applications.png

Spec


SPECIFICATIONS

FUNCTIONS

MANAGEMENT

INTERFACE

•Easy remote monitoring via iPhone, iPad, Android, PC & Mac
•69 degree diagonal viewing angle
•Supports dynamic DNS service
•IR filer embedded

•EdiView Finder (Windows/Mac)
•16-channel viewer
•Web management interface
•Firmware upgradable
•iPhone & iPad viewer app
•Android viewer app

•10/100Mbps Fast Ethernet (RJ-45) port
•Power jack
•Reset/WPS button
•Internal antenna
•LED indicators: Internet, LAN/Wi-Fi LNK/ACT, Power

VIDEO

VIDEO SETTINGS

SUPPORTED PROTOCOLS

•High-speed H.264 & MJPEG video compression
•1280 x 720 at up to 24 fps
•640 x 480 at up to 30 fps
•320 x 240 at up to 30 fps

•Resolution: HD (1280 x 720), VGA (640 x480), QVGA (320 x 240)
•Frame rate: 5, 10, 15, 20, 24 or 30 fps

•v4, HTTP, TCP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, SNTP, FTP, DHCP, ARP, DNS, PPPoE

STANDARDS

RF OUTPUT POWER

IR LEDS

•Fast Ethernet IEEE 802.3/802.3u
•Wireless IEEE 802.11b/g/n

•11b: 16~18dBm
•11g: 14~16dBm
•11n: 11~13dBm

•IR LEDs for night illumination up to 15 feet
