BR-6478AC V2

AC1200 Gigabit Dual-Band Wi-Fi Router with USB Port & VPN

  • AC1200 High-Speed: Next generation 802.11ac Wi-Fi standard
  • 5 Modes in 1: Router, Access Point, Wi-Fi Range Extender, Wi-Fi Bridge and WISP
  • Backward Compatible: Compatible with 802.11a/b/g/n standards
  • Concurrent Dual-Band: Wireless connectivity for 2.4GHz and 5GHz
  • Gigabit: 5-port gigabit Ethernet connectivity
  • VPN (Virtual Private Network): Access secure, remote networks from anywhere and protect privacy on public Wi-Fi and bypass Internet censorship
  • USB Port: Storage & FTP file or printer sharing as your own private, secure cloud
  • Multiple SSIDs & VLAN: Supports up to 10 SSIDs (2.4GHz x 5 & 5GHz x 5) and provides security and protecting confidential or critical network resources (*Access point mode only)
  • Guest Network: Provides secure & private connectivity while isolating guests from your primary network (*Router mode only)
  • Smart iQ Setup: Smart, automatic and quick web-based installation with no CD required from any smartphone, iPad, tablet, or PC
  • iQoS Bandwidth Management: Efficient and effective internet bandwidth management

Next-Generation Wireless Networking

The Edimax BR-6478AC V2 router supports the next generation IEEE 802.11ac wireless standard, meaning higher data rates in the 5GHz band. With 300Mbps speeds in the 2.4GHz band and 867Mbps speeds in 5GHz, the BR-6478AC V2 is ideal for HD video streaming and large file transfers. The router is also backward compatible with 802.11a/b/g/n to ensure compatibility with legacy Wi-Fi devices.




Concurrent Dual-Band Wi-Fi Connectivity
The Edimax BR-6478AC V2 router provides simultaneous 2.4GHz (802.11n) and 5GHz (802.11ac) wireless network connectivity for maximum flexibility of use.

VPN Access for Privacy & Security
Built-in Virtual Private Network (VPN) support for easy VPN access on all your devices. VPNs enable you to access secure, remote networks from anywhere and can offer privacy and security online. Log in to your work/school network remotely or avoid geoblocking, protect privacy on public Wi-Fi and bypass Internet censorship.

Home Users: Avoid regional restrictions and access geoblocked content such as Netflix or iPlayer from anywhere. Ensure your privacy and anonymity online and defeat censorship and other location-based content restrictions. You can also remotely access your home network when you’re away, and use your encrypted VPN for security when out and about using potentially unsafe public Wi-Fi hotspots.

Small Office Users: Enable your employees to access company resources remotely such as email, documents saved on the company server and any programs/systems when they are outside the office.

Multi-Function USB Port
Connect a USB hard-drive and enjoy your own private cloud storage. Keep content on your central storage and access it from any device on your network, such as movie and TV streaming to PCs or smart TVs, or for regular backups of vital data. With the built-in VPN function you can even access your network remotely when you’re away from home. It can also be used with an FTP server or printer, so any devices on your network can print over your Wi-Fi.



Smart iQ Setup
Features iQ Setup for smart, automatic and quick installation with no CD required, no smartphone app downloaded, and no PC required.


5-in-1 Router, Access Point, Range Extender , Wireless Bridge and WISP
The BR-6478AC V2 can work as router, access point, range extender, wireless bridge or WISP. Just configure the mode you need for your network environment using the smart iQ Setup wizard.



High Gain Antennas For Better Wi-Fi Performance
Employing two external high-gain fixed antennas,  the BR-6478AC V2 provides powerful 2.4GHz and 5GHz dual-band signal strength and enhances Wi-Fi range, providing signal penetration through walls and floors across your home or office.

Edimax’s Revolutionary iQoS
iQoS is Edimax’s solution for a quicker, easier, and more effective way to manage Internet bandwidth. While Quality of Service (QoS) functionality is a common feature in routers across the market, typically only advanced users have the knowledge required to set up the complex parameters. Edimax though has redesigned QoS with user-friendliness and accessibility in mind. A simple and intuitive user interface allows users to arrange bandwidth priority settings in just a few clicks. With iQoS, you can enjoy gaming, video streaming, VoIP applications and BT clients at the same time without the usual nightmare of lag and interruptions. An original, efficient and effective means of managing your Internet bandwidth.



Multi-SSID & VLAN Support*
Multi-SSID enables users to configure up to ten separate SSIDs (2.4GHz x 5 and 5GHz x 5) in order to group and manage users according to your requirements. In addition, each SSID can be assigned a different VLAN ID, so users with multiple VLANs can manage the network access level of each SSID – ensuring security and protecting confidential or critical network resources.
*Access point mode only

Guest Network*
Supports a guest network to provide connectivity while isolating guests from your primary network.
*Router mode only

APPLICATION DIAGRAM

Specification Version 2.4.0 Copyright © 2014-2016 Almsaeed Studio. All rights reserved. Layout Options Fixed layout Activate the fixed layout. You can't use fixed and boxed layouts together Boxed Layout Activate the boxed layout Toggle Sidebar Toggle the left sidebar's state (open or collapse) Sidebar Expand on Hover Let the sidebar mini expand on hover Toggle Right Sidebar Slide Toggle between slide over content and push content effects Toggle Right Sidebar Skin Toggle between dark and light skins for the right sidebar Skins Blue Black Purple Green Red Yellow Blue Light Black Light Purple Light Green Light Red Light Yellow Light

Spec




Brand
EDIMAX
Model
BR-6478AC V2
WiFi Technology
IEEER 802.11a/b/g/n/ac
Speed and range
1.2Gbps
WiFi Performance
AC1200 WiFi
WiFi Band
Simultaneous dual band 2.4 & 5GHz
Standards
- IEEE® 802.11 b/g/n 2.4GHz
- IEEE® 802.11 a/n/ac 5GHz
Number of ethernet ports
5* 10/100/1000 Mbps—(1 WAN & 4 LAN Gigabit Ethernet ports)
Number of USB ports
USB 2.0 port
Memory
8MB Flash 64MB RAM
Antenna
2 *Dual-band antennas
Button
Power On/Off
WiFi security
- WEP, WPA and WPA2 security
- QoS for critical operations
- SPI anti-DoS firewall
Technical Specifications
& Key Features
- Supports router, access point,  Wi-Fi range extender, Wi-Fi Bridge & WISP modes
- Supports Open VPN Server for private network with high security & flexible
- DNS proxy for filtering and monitoring illegal DNS traffic
- Guest network
- Up to 10 SSIDs (2.4GHz x 5 and 5GHz x 5) with VLAN support in AP mode
- IGMP proxy and IGMP snooping
- DDNS and DHCP
- Port triggering for special applications
- Virtual server and DMZ hosting
- MAC/IP filter and URL blocking
- iQoS for smart bandwidth management
- Static routing
- UPnP architecture
- Wi-Fi schedule control
Physical Specifications
- 190.2mm x 172mm x 42mm
- 322g
Package Contant
- Broadband router (main body, 1 pcs)
- Quick Installation Guide (1 pcs)
- One CD-ROM (Including the Setup Wizard, Multi-languages Quick Installation Guide and User Manual)
- 12V DC power adapter (1 pcs)
- Ethernet Cable
